Brand:
COMP Cams
Manufacturer's Part Number:
12-430-8
Part Type:
Camshafts
Product Line:
COMP Cams Magnum Retrofit Camshafts
UPC:
036584700272
Cam Style:
Hydraulic roller, Retro-fit
Camshaft Use:
Street/Strip
Basic Operating RPM Range:
2,000-5,500
Intake Duration at 050 inch Lift:
224
Exhaust Duration at 050 inch Lift:
224
Duration at 050 inch Lift:
224 int./224 exh.
Advertised Intake Duration:
280
Advertised Exhaust Duration:
280
Advertised Duration:
280 int./280 exh.
Intake Valve Lift with Factory Rocker Arm Ratio:
0.525 in.
Exhaust Valve Lift with Factory Rocker Arm Ratio:
0.525 in.
Valve Lift with Factory Rocker Arm Ratio:
0.525 int./0.525 exh.
Lobe Separation (degrees):
110
Remanufactured:
No
Computer-Controlled Compatible:
No
Grind Number:
CS 280H-R10
Valve Springs Required:
Yes
Quantity:
Sold individually.
Notes:
Retro-fit: Designed for early non-roller blocks. Requires thrust button and wear plate.
COMP Cams Magnum Retrofit Camshafts
COMP Cams Magnum retrofit camshafts are designed for everyone from the serious street performance enthusiast to the all-out competition drag racer. Whether you're driving a street rod, show car with power accessories, a super gas, or super competition car on alcohol, COMP Cams will fit your engine's needs.
